Fineco-201E RS-232 / RS-422 / RS-485 Converter (port powered)

RS232 /RS485 converter

  • Fineco
Quantity:

           Fineco-201E RS-232 / RS-422 / RS-485 Converter (port powered)
转接头1

1


Main Functions and features:
Finco-201E is a light weighted, compact and robust port powered RS-232 to RS-485/422 Interface Converter

RS-232 / RS-422 / RS-485 over Fast Ethernet Media Converter performance parameter

 Interface feature: RS-232C,RS-485 standard interface Compatible with EIA,TIA

Electric interface: RS-232 end DB9 female (hole-type), RS-485 end DB9 male (needle-type) connector, with connection pole

Working mode: asynchronous half-duplex difference transmission;

Transmission media: twisted-pair or STP

Transmissionrate:300-115.2Kbps

Dimension: 63mm×35mm×17mm

Working circumstance:-40 to 85 degree C, relative humidity 5% to 95%

Transmission distance: 1,200m (RS-485end), 5m (RS-232end)

Protection Level: RS-485 interface 600V lightning surge protection in each line
